In this section we review the use of listings, tables and tree diagrams to calculate the probabilities of two events.
An unbiased coin is tossed twice.
List all the possible outcomes.
H H
H T
T H
T T
What is the probability of obtaining two heads?
p(2 heads) =
What is the probability of obtaining a head and a tail in any order?
p(a head and a tail)  =  =
A red dice and a blue dice, both unbiased, are rolled at the same time. The scores on the two dice are then added together.
Use a table to show all the possible outcomes.
Blue Dice

1  2  3  4  5  6
1  2  3  4  5  6  7
2  3  4  5  6  7  8
3  4  5  6  7  8  9
4  5  6  7  8  9  10
5  6  7  8  9  10  11
6  7  8  9  10  11  12
What is the probability of obtaining:
(i)  a score of 5,

There are 4 ways of scoring 5, so:

(ii)  a score which is greater than 3,
There are 33 ways of obtaining a score greater than 3, so:

(iii)  a score which is an even number?
There are 18 ways of obtaining a score which is an even number, so:

A card is taken at random from a pack of 52 playing cards, and then replaced. A second card is then drawn at random from the pack.
Use a tree diagram to determine the probability that:
p(Diamond) =  =  and p(not Diamond) =  =  .
both cards are Diamonds,
p(both Diamonds)  =
at least one card is a Diamond,
p(at least one Diamond)  =  +  +  =
exactly one card is a Diamond,
p(exactly one Diamond)  =  +  =  =
neither card is a Diamond.
p(neither card a Diamond)  =
